型号 |
额定输出功率(KW) |
输入电流(A) |
额定输出电流(A) |
适配电机(KW) |
|
单相输入电源:220V(-15%～+15%)，50/60Hz |
||||
|
Q22-2S0004H |
0.4 |
6.5 |
2.3 |
0.4 |
|
Q22-2S0007H |
0.75 |
8.2 |
4 |
0.75 |
|
Q22-2S0015H |
1.5 |
14 |
7.0 |
1.5 |
|
Q22-2S0022H |
2.2 |
23 |
9.6 |
2.2 |
|
Q22-2S0037H |
3.7 |
32.0 |
17.0 |
3.7 |
|
Q22-2S0055H |
5.5 |
45.0 |
25.0 |
5.5 |
|
三相输入电源:380V(-15%～+15%)，50/60Hz |
||||
|
Q22-4T0007H |
0.75 |
3.5 |
2.5 |
0.75 |
|
Q22-4T0015H |
1.5 |
6.2 |
4.0 |
1.5 |
|
Q22-4T0022H |
2.2 |
9.2 |
5.5 |
2.2 |
|
Q22-4T0030H |
3.0 |
9.2 |
6.8 |
3.0 |
|
Q22-4T0040H |
4.0 |
14.9 |
9 |
4.0 |
|
Q22-4T0055H |
5.5 |
21.5 |
13 |
5.5 |
|
Q22-4T0075H |
7.5 |
28.9 |
18 |
7.5 |
|
Q22-4T0110H |
11 |
39.0 |
24 |
11 |
|
Q22-4T0150H |
15 |
50.3 |
33 |
15 |
|
Q22-4T0180H |
18 |
60.0 |
38 |
18 |
|
Q22-4T0220H |
22 |
69.3 |
45 |
22 |
|
Q22-4T0300H |
30 |
86 |
60 |
30 |
|
Q22-4T0370H |
37 |
104 |
75 |
37 |
|
Q22-4T0450H |
45 |
124 |
91 |
45 |
|
Q22-4T0550H |
55 |
150 |
112 |
55 |
|
Q22-4T0750H |
75 |
160 |
150 |
75 |
|
Q22-4T0900H |
90 |
180 |
175 |
90 |
|
Q22-4T1100H |
110 |
196 |
210 |
110 |
|
Q22-4T1320H |
132 |
232 |
250 |
132 |
|
Q22-4T1600H |
160 |
282 |
300 |
160 |
|
Q22-4T2000H |
200 |
385 |
377 |
200 |
|
Q22-4T2200H |
220 |
430 |
426 |
220 |
|
Q22-4T2500H |
250 |
468 |
465 |
250 |
|
Q22-4T2800H |
280 |
552 |
520 |
280 |
|
Q22-4T3150H |
315 |
590 |
585 |
315 |
|
Q22-4T3550H |
355 |
665 |
585 |
355 |
A型
B型
|
框号 |
型号 |
外型尺寸(MM) |
安装尺寸(MM) |
|||||
|
W |
H |
D |
W1 |
W2 |
H1 |
孔径 |
||
|
A型 |
Q22-2S0004H |
76 |
200 |
154 |
66 |
52.7 |
191.6 |
M4 |
|
Q22-2S0007H |
||||||||
|
Q22-2S0015H |
||||||||
|
Q22-2S0022H |
||||||||
|
Q22-4T0007H |
76 |
200 |
154 |
66 |
52.7 |
191.6 |
M4 |
|
|
Q22-4T0015H |
||||||||
|
Q22-4T0022H |
||||||||
|
Q22-4T0020H |
||||||||
|
Q22-4T0040H |
||||||||
|
Q22-2S0037H |
100 |
242 |
155.5 |
84 |
86.6 |
224.6 |
M5 |
|
|
Q22-2S0055H |
||||||||
|
Q22-4T0055H |
100 |
242 |
155.5 |
84 |
86.6 |
224.6 |
M5 |
|
|
Q22-4T0075H |
||||||||
|
Q22-4T0110H |
116 |
320 |
175.5 |
98 |
100 |
201 |
M5 |
|
|
Q22-4T0150H |
||||||||
|
Q22-4T0180H |
||||||||
|
Q22-4T0220H |
142 |
372 |
220 |
124 |
100 |
372 |
M6 |
|
|
Q22-4T0200H |
||||||||
|
B型 |
Q22-4T0370H |
256 |
470 |
222 |
196 |
- |
450 |
M7 |
|
Q22-4T0450H |
||||||||
|
Q22-4T0550H |
320 |
560 |
240 |
220 |
- |
543 |
M10 |
|
|
Q22-4T0750H |
||||||||
|
Q22-4T0900H |
404 |
597 |
249 |
270 |
- |
580 |
M10 |
|
|
Q22-4T1100H |
||||||||
|
Q22-4T1320H |
464 |
745 |
325 |
343 |
- |
715 |
M12 |
|
|
Q22-4T1600H |
||||||||
|
Q22-4T1850H |
363 |
940 |
482 |
198 |
- |
909 |
M16 |
|
|
Q22-4T2000H |
||||||||
|
Q22-4T2200H |
||||||||
|
Q22-4T2500H |
373 |
1140 |
547 |
198 |
- |
1109 |
M16 |
|
|
Q22-4T2800H |
||||||||
|
Q22-4T3150H |
||||||||
